Description:
Our Moxon Vise Lite is perfect for woodworkers that want to make dovetails, mortise and tenon joinery, or to build drawers, chairs or other casework projects but don't need the extra capacity of our normal Moxon Vise. You also can secure this Moxon Vise to a sturdy kitchen table or picnic table, so you don't even have to own a workbench in order to make use of this amazing workholding tool.

Moxon Vise Lite:

  • Dovetailer's dream vise
      • Accommodates up to 14" wide boards, perfect for dovetailing drawers
      • Holds the board securely along it's entire width, no shaky boards while sawing
      • Brings the board up to a  more comfortable working height
  • Ultra Portable
      • Less than 24” long
      • Approx. 7-1/2 lbs, about half of the weight of our standard Moxon vise
      • Clamp it to your workbench, clamp it to your kitchen table
      • Stores easily when not in use
  • Perfect for the experienced as well as the new or junior woodworker
Technical Specs
  • Solid hard maple - unfinished
  • Vise Screws
      • Approx.size = 12" overall length
      • Hand grip approx.size = 1-7/8" Diameter x 4-1/2" long
      • Threaded section approx.size = 1-1/4" Diameter x 7-1/2" long
      • Thread pitch = 4 Turns Per Inch (TPI)
      • Vise Screws (ready to finish)
  • Front Jaw
      • Approx. size 1-1/4" thick x 4" tall x 19-3/4" long
      • Front Jaw has an 1/8" overhang which is used to align the vise to the front of the workbench
      • Oblong shaped clearance holes on front vise jaw allows clamping of tapered objects
      • Milled surfaces, ready to sand and finish
  • Rear Jaw
      • Approx. size 1-3/4" thick x 3-7/8" tall x 23-3/4" long
      • Milled surfaces, ready to sand and finish
  • Vise Capacity & Weight
      • Clamp up to 4-1/4" between the jaws
      • 14-1/4" space between the screws
      • Approx. 7-1/2 lbs

    (Leadtime = Ships within 2-3 weeks)

    Moxon Vise Review Video (From "Workbench Review")





    $ 149.00
